LED Display – Module P6 Full Color SMD Outdoor RGB
Module P6.1.2.3.4.5.8.10 Full Color SMD LED Module
p6 LED Display – Module P6 Full Color SMD Outdoor RGB A P6 LEDs p2 has emerged as a transformative technology, offering unparalleled clarity, brightness, and versatility. Businesses and organizations seek innovative ways to capture audience attention and convey messages effectively. The P6 LED Screen stands out as a premier choice. Which ensures high-resolution images and videos. LED Board Prices in Bangladesh start. The price varies on product quality and quantity.Â
P6 LEDs p5 Displays Module Specification
| LED Lamp Specification | ||||||
| Color | Package | Intensity | Viewing angle | Wavelength | Testing condition | |
| Red | 3 IN 1 SMD | 70-100mcd | 140°/120° | 620-625nm | 25℃,20mA | |
| Green | 120-200mcd | 140°/120° | 515-530nm | 25℃,10mA | ||
| Blue | 30-40mcd | 140°/120° | 465-475nm | 25℃,5mA | ||
| Module Parameter | ||||||
| Pixel Pitch | P6mm | |||||
| Pixel Structure | 3 IN 1 SMD | |||||
| Density | 27777pixels/㎡ (real pixel) | |||||
| Module Resolution | 32pixel(L) * 32pixel(H) | |||||
| Module Dimension | 192mm(L) * 192mm (H) * 15mm(D) | |||||
| Cabinet Dimension | 192*192mm | |||||
| Cabinet Weight | .5 (kg) | |||||
| Single Point Brightness, Chroma Correction: Support | ||||||
| White Balance Brightness | ≥4500 cd/㎡ | |||||
| Viewing Angle | 140°(Horizontal)； 120°(Vertical) | |||||
| Best Viewing Distance | ≥12+m | |||||
| Color Temperatures | 2000K-12500K (adjustable) | |||||
| Display Color | 68.7 billion Color | |||||
| Brightness Uniformity | ≥97% | |||||
| Contrast Ratio | ≥5000:1 | |||||
| Process Performance | ||||||
| Single Processing bits | 16bits*3 | |||||
| Gray Scale | 12-16Bit | |||||
| Control Distance | Cable:100m, Optical Fiber:10KM | |||||
| Drive Mode | Constant current source driver | |||||
| Frame rate | ≥60Hz | |||||
| Regress rate | 1920-3840Hz | |||||
| Way to control | Synchronize | |||||
| Brightness adjustment range | 0-100 Stepless | |||||
| Brightness Correction | Pixel by pixel, module by module, cabinet by cabinet | |||||
| User Parameter | ||||||
| Working Temperature | -20～+50 ºC | |||||
| Stored Temperature | -30～+60 ºC | |||||
| Working Humidity | 10%～80% RH | |||||
| Lifetime | 100,000 hours | |||||
| MTBF | 5000 hours | |||||
| Continuous Working Time | ≥72 hours | |||||
| IP Protection Grade | IP65 | |||||
| Out of Control Pixel Rate | ≤0.01% | |||||
| Electricity Parameter | ||||||
| Operating Voltage | DC 4.5-5V | |||||
| Power Requirements | AC 220 x (1±10%) V, 50x (1±10%) Hz | |||||
| Max. Power Consume | 850w/m2 | |||||
| Average Power Consume | 300w/m2 | |||||
P6 LED Display
High-Resolution and Clarity: The P6 LED display. The 6mm pixel pitch means that the distance between each pixel is only 6mm, resulting in a dense pixel. Configuration that delivers crystal-clear images even at close viewing distances. This makes P6 LED display perfect for settings where detail and clarity are paramount. Brightness and Visibility: One of the standouts features of P6 the display is its exceptional brightness levels. Ensuring that the content remains visible and impactful even in direct sunlight. The high brightness, combined with superior contrast ratios, makes P6 display a preferred choice for outdoor advertising and public information displays. This energy efficiency translates to lower operating costs and a reduced carbon footprint, making P6 LED display an environmentally friendly option for businesses and organizations.
Applications of P6 LED Display
Advertising and Marketing: In the competitive world of advertising, capturing and retaining audience attention is crucial. P5 LED display offers an edge with their high-definition visuals and dynamic content capabilities. That are visually striking and engaging, driving higher brand recall and customer engagement. Corporate and Educational Settings: For corporate presentations, conferences, and educational environments, the PLED display provides a professional and impactful medium for communication. The high resolution ensures that every detail of the presentation. Is conveyed clearly, enhancing understanding and retention. Their ability to display live feeds, animations, and special effects makes them an indispensable part of modern event production.
Technical Specifications of P6 LED Display – Module P6 Full Color SMD Outdoor RGB
- Pixel Density and Resolution: The pixel density of a P6 LED display is a key determinant of its visual quality. With a pixel pitch of 6mm, these displays offer a high pixel density, resulting in a resolution that can exceed 1000 pixels per square meter. This high pixel density ensures that even large displays deliver sharp and detailed images.
- Refresh Rate and Color Accuracy: P6 is designed with high refresh rates, typically ranging from 960Hz to 3840Hz. This high refresh rate ensures smooth and flicker-free visuals, which is essential for displaying video content and animations.
- Durability and Longevity:Â Durability is critical. They are designed to withstand various environmental conditions. The robust construction and high-quality materials used in P3 LED display ensure a long operational life, making them a cost-effective investment for businesses.
Advantages of P6 LED Display Over Traditional Displays
- Scalability and Flexibility:Â P6 LED display is highly scalable and flexible, allowing for custom configurations and sizes. This scalability makes them suitable for a wide range of applications, from small indoor displays to large outdoor billboards.
- The energy efficiency, durability, and low maintenance requirements of P6 LED displays result in lower operating costs over their lifespan.
P6 LED Display Price in Bangladesh
- Small Indoor Displays (Up to 100 inches): For small indoor display price range start from BDT 5,000 to BDT 7,000. These screens are commonly used in corporate settings, retail environments, and small event venues.
- Medium-sized Displays (100 to 300 inches): Medium-sized display is suitable for larger indoor spaces and some outdoor applications. Prices for these displays typically range from BDT 8,000 to BDT 10,000.
- Large Outdoor Displays (Above 300 inches): Large outdoor display which is often used for advertising. And public information displays, can range from BDT 10,000 to BDT 12,000 or more, depending on the specific requirements and features.
Where to Buy P5 LED Displays in Bangladesh
Authorized Dealers:Â Purchasing from authorized dealers ensures that you get genuine products with warranties and after-sales support. Some well-known dealers in Bangladesh include:
- adkey Limited
Conclusion
The P6 LED display represents a significant advancement in technology, offering unparalleled visual quality, versatility, and energy efficiency. As businesses continue to seek innovative ways to stand out and capture attention LED Display – Module P6 Full Color SMD Outdoor RGB.
